The M12 low distortion lens has a compact design and its images have low distortion and high precision, which can meet the strict requirements of industrial environments for image quality and stability.
Therefore, the M12 low distortion lens has a wide range of applications in industrial inspection. Before understanding the application of M12 low distortion lens, we can first understand its advantages and characteristics.
1.The core advantages of M12 low distortion lens
(1)Compact and lightweight
The M12 low distortion lens is a miniaturized lens designed for the M12 mount. It is small in size and light in weight, making it suitable for installation in industrial equipment with limited space.
(2)Low distortion imaging
The low distortion characteristics of the M12 low-distortion lens ensure that the geometry of the captured image is consistent with the actual object, reducing errors in measurement and inspection. In industrial inspections requiring high precision, low-distortion lenses can provide more reliable data support.
(3)Excellent optical performance
M12 low distortion lenses usually use high-quality optical glass and optimize optical design to reduce aberrations and provide high-resolution images.
(4)Strong environmental adaptability
M12 low distortion lenses are typically housed in metal, making them rugged and durable enough to withstand the vibrations, shocks, and temperature changes found in industrial environments.
Advantages of M12 low distortion lens
2.Application of M12 low distortion lens in industrial inspection
M12 low distortion lenses are widely used in industrial inspection, mainly in the following application scenarios:
(1)Dimensional measurement
In industrial production, precise measurement of product dimensions is essential to ensure that product quality meets standards. The high resolution and precise imaging capabilities of the M12 low-distortion lens enable it to be used to accurately measure the size and shape of objects. It is widely used in precision dimensional measurement, such as the inspection of small parts such as electronic components, gear pitch, and hardware.
The low distortion characteristics of the M12 low-distortion lens ensure geometric fidelity of the image, avoiding measurement errors introduced by lens distortion and enabling high-precision dimensional measurement.
(2)Barcode scanning and recognition
The high resolution and large depth of field design of the M12 low-distortion lens can clearly capture barcode details and provide clear barcode images, thereby improving scanning speed and accuracy, enabling it to read barcode information quickly and accurately. The M12 low distortion lens is mainly used in barcode scanning and recognition in logistics, packaging, medical and other industries.
M12 low distortion lens is often used for barcode scanning and recognition
(3)Surface defect detection
The M12 low distortion lens can clearly capture tiny details on the product surface, such as scratches, cracks, holes, bubbles and other defects, which is crucial to ensuring product quality. Its low distortion allows it to accurately reflect the true condition of the product surface, avoiding inspection errors caused by lens distortion, thereby improving inspection accuracy and reliability.
For example, when used in material defect identification, the M12 low-distortion lens can detect scratches, pits, and bubbles on materials such as metal, glass, and plastic. Low-distortion imaging can ensure the true restoration of the defect location and shape.
In the production of plastic molded products, this lens can detect surface defects such as flash, bubbles, shrinkage, and weld marks, helping companies adjust production processes and improve product appearance quality and yield. In textile production, the M12 low distortion lens can be used to detect surface defects on fabrics, such as yarn defects, holes, oil stains, and color differences.
M12 low distortion lens is often used for surface defect detection
(4)Automatic detection and positioning
The M12 low distortion lens can help achieve high-precision positioning and alignment in automated production lines, and is mainly used in automated assembly, sorting, welding, etc.
For example, in semiconductor packaging and 3C product assembly, M12 low-distortion lenses can be used for robot vision guidance, providing precise geometric information to help robots achieve millimeter-level positioning, accurately identify component positions, and assist robotic arms in high-precision grasping and bonding, such as grasping automotive parts or planning precision welding paths.
(5)Medical and food packaging testing
The M12 low-distortion lens, combined with high dynamic range technology, delivers clear images in complex lighting conditions, meeting hygiene and safety standards. It is commonly used for testing the seals of pharmaceutical packaging and identifying foreign objects in food.
For example, on food and pharmaceutical production lines, the M12 low-distortion lens can detect foreign objects (such as metal fragments and plastic particles) in products to ensure that product quality meets requirements.
M12 low distortion lenses are also commonly used in medical and food packaging inspections
(6)3D reconstruction and detection
Combined with structured light or laser scanning technology, the M12 low-distortion lens can be used for 3D object detection and reconstruction, and is suitable for the detection of industrial parts with complex shapes. When used in a multi-lens configuration, its low distortion reduces stitching errors and ensures the accuracy of 3D models, making it suitable for high-precision industrial applications such as industrial CT, 3D modeling, and logistics sorting.
In summary, the M12 low distortion lens can meet the inspection needs of various industrial scenarios and has important applications in industrial inspections such as electronics manufacturing, automotive industry, food packaging, medicine, and logistics, helping companies improve production efficiency and product quality while reducing costs and maintenance difficulties.
Final Thoughts:
ChuangAn has carried out the preliminary design and production of M12 low distortion lenses, which are widely used in various fields. If you are interested in or have needs for M12 low distortion lenses, please contact us as soon as possible.
