Gambar Unggulan Lensa Fisheye 1/3″
  • Lensa Fisheye 1/3″
  • Lensa Fisheye 1/3″
  • Lensa Fisheye 1/3″

Lensa Fisheye 1/3″

Katrangan Ringkes:

  • Lensa Fisheye kanggo Sensor Format 1/3″
  • 5 nganti 8 Mega Piksel
  • Lensa Dudukan M8/M12
  • Dawane Fokus 0,98mm nganti 1,8mm
  • Sudut Pandang nganti 225°


Produk

Rincian Produk

Tag Produk

Model Format Sensor Dawane Fokus (mm) FOV (H*V*D) TTL (mm) Filter IR Bukaan Gunung Rega Unit
cz cz cz cz cz cz cz cz cz
CH3877CB-1
Lensa Fisheye 1/2.9" 1.83mm 5MP F2.0 M12 Mount kanggo Sensor Gambar GC2053
Gambar PDF

Model

CH3877CB

Tipe

Lensa Mata Iwak

Sederek lara.

>50%

Resolusi

5MP

Kepala Ray Angle

<19°

Format Gambar

1/2.9″

MOD

0.1m~∞

Lingkaran Gambar

f6.3mm (MAX)

Tipe Pemasangan

M12*P0.5

EFL

1.83mm

Gambar Dimensi

ф16.00*P 10.58mm

TTL (Teks Lengkap)

13,36mm

Struktur Lensa

4G2P

F/ORA.

2.0

Filter IR

IR650nm

FFL(M)

2,78mm

Tahan banyu

IP69K

BFL(O)

3.21mm

Operasi Iris

Didandani

Kanggo Sensor

GC2053

Operasi Zoom

Didandani

FOV (Foto)

Horisontal

170°

Operasi Fokus

Pandhuan

Vertikal

94°

Suhu Operasi

-40°~+85°

Diagonal

202°

Suhu Panyimpenan

-40°~+85°

Distorsi F-Theta

<-8%


CH310A-1
Lensa Fisheye 1/3" 1.08mm F2.2 205 Derajat M12 Mount
Gambar PDF

Model

CH310A

Tipe

Lensa Mata Iwak

Sederek lara.

>68%

Resolusi

4MP

Kepala Ray Angle

<20.26°

Format Gambar

1/3″

MOD

0.1m~∞

Lingkaran Gambar

f6.0mm (MAX)

Tipe Pemasangan

M12*P0.5

EFL

1,08mm

Gambar Dimensi

ф14.00*P 10.85mm

TTL (Teks Lengkap)

12,08mm

Struktur Lensa

6G

F/ORA.

2.2

Filter IR

T=50%&IR650±10nm

FFL(M)

1.23mm

Bobot

4.1g

BFL(O)

2.31mm

Operasi Iris

Didandani

Kanggo Sensor

OV4689

Operasi Zoom

Didandani

FOV (Foto)

Horisontal

205°

Operasi Fokus

Pandhuan

Vertikal

205°

Suhu Operasi

-20°~+85°

Diagonal

205°

Suhu Panyimpenan

-20°~+85°

Distorsi TV

<-117,7%


CH2503
Lensa Fisheye M12 1/3" 0.98mm 5MP 225 Derajat
Gambar PDF

Model

CH2503C

Tipe

Lensa Mata Iwak

Sederek lara.

>98%

Resolusi

5MP

Kepala Ray Angle

<13.4°

Format Gambar

1/3″

MOD

0.1m~∞

Lingkaran Gambar

f3.0mm (V-MAX)

Tipe Pemasangan

M12*P0.5

EFL

0,98mm

Gambar Dimensi

ф14.00*P13.10mm

TTL (Teks Lengkap)

14,85mm

Struktur Lensa

6G

F/ORA.

2.8

Filter IR

Non-IR

FFL(M)

1,75mm

Bobot

4.4g

BFL(O)

3,05mm

Operasi Iris

Didandani

Kanggo Sensor

∅3.1

Operasi Zoom

Didandani

FOV (Foto)

Horisontal

225°

Operasi Fokus

Pandhuan

Vertikal

225°

Suhu Operasi

-20° ~+85°

Diagonal

225°

Suhu Panyimpenan

-20° ~+85°

Distorsi TV

<-81%


CH2503
Lensa Fish Eye 1/3" 0.98mm 225 Derajat F2.8 M12 Mount
Gambar PDF

Model

CH2503CB

Tipe

Lensa Mata Iwak

Sederek lara.

>98%

Resolusi

5MP

Kepala Ray Angle

<13.4°

Format Gambar

1/3″

MOD

0.1m~∞

Lingkaran Gambar

f3.0mm (V-MAX)

Tipe Pemasangan

M12*P0.5

EFL

0,98mm

Gambar Dimensi

ф14.00*P13.10mm

TTL (Teks Lengkap)

14,85mm

Struktur Lensa

6G

F/ORA.

2.8

Filter IR

T=50%&IR650±10nm

FFL(M)

1,75mm

Bobot

4.4g

BFL(O)

3,05mm

Operasi Iris

Didandani

Kanggo Sensor

∅3.1

Operasi Zoom

Didandani

FOV (Foto)

Horisontal

225°

Operasi Fokus

Pandhuan

Vertikal

225°

Suhu Operasi

-20° ~+85°

Diagonal

225°

Suhu Panyimpenan

-20° ~+85°

Distorsi TV

<-81%
CH2503
0.98mm 225 Derajat Kanthi Lensa Fisheye Mount M12 kanggo Sensor 1/3
Gambar PDF

Model

CH2503D

Tipe

Lensa Mata Iwak

Sederek lara.

>98%

Resolusi

5MP

Kepala Ray Angle

<13.4°

Format Gambar

1/3″

MOD

0.1m~∞

Lingkaran Gambar

f3.0mm (V-MAX)

Tipe Pemasangan

M12*P0.5

EFL

0,98mm

Gambar Dimensi

ф15.00*P13.10mm

TTL (Teks Lengkap)

14,85mm

Struktur Lensa

6G

F/ORA.

2.8

Filter IR

T=50%&IR650±10nm

FFL(M)

1,75mm

Bobot

4.4g

BFL(O)

3,05mm

Operasi Iris

Didandani

Kanggo Sensor

∅3.1

Operasi Zoom

Didandani

FOV (Foto)

Horisontal

225°

Operasi Fokus

Pandhuan

Vertikal

225°

Suhu Operasi

-20° ~+85°

Diagonal

225°

Suhu Panyimpenan

-20° ~+85°

Distorsi TV

<-81%
CH3596
Lensa Panorama 1/3" 1.3mm 220 Derajat 5MP IP68 M12
Gambar PDF

Model

CH3596A

Tipe

Lensa Mata Iwak

Sederek lara.

>90%

Resolusi

5MP

Kepala Ray Angle

<20º

Format Gambar

1/3″

MOD

0.1m~∞

Lingkaran Gambar

f3.6mm (V-MAX)

Tipe Pemasangan

M12*P0.5

EFL

1.3mm

Gambar Dimensi

ф14.00-∅16.00*L10.84mm

TTL (Teks Lengkap)

13mm

Struktur Lensa

6G

F/ORA.

1.8

Filter IR

T=50%@650nm±10nm

FFL(M)

2.16mm

Bobot

5.0g

BFL(O)

3,06mm

 Tahan banyu

IP68

Kanggo Sensor

PS5268

 Operasi Iris

Didandani

FOV (Foto)

Horisontal

230°

 Operasi Zoom

Didandani

Vertikal

148°

 Operasi Fokus

Pandhuan

Diagonal

230°

 Suhu Operasi

-20°~+85°

Distorsi TV

<-80%

  Suhu Panyimpenan -20°~+85°
CH3596
Lensa Fisheye 1.3mm 220 Derajat M12 kanggo Sensor 1/3
Gambar PDF

Model

CH3596AB

Tipe

Lensa Mata Iwak

Sederek lara.

>90%

Resolusi

5MP

Kepala Ray Angle

<20º

Format Gambar

1/3″

MOD

0.1m~∞

Lingkaran Gambar

f3.6mm (V-MAX)

Tipe Pemasangan

M12*P0.5

EFL

1.3mm

Gambar Dimensi

ф14.00-∅16.00*L10.84mm

TTL (Teks Lengkap)

13mm

Struktur Lensa

6G

F/ORA.

1.8

Filter IR

BP940nm

FFL(M)

2.16mm

Bobot

5.0g

BFL(O)

3,06mm

 Tahan banyu

IP68

Kanggo Sensor

PS5268

 Operasi Iris

Didandani

FOV (Foto)

Horisontal

230°

 Operasi Zoom

Didandani

Vertikal

148°

 Operasi Fokus

Pandhuan

Diagonal

230°

 Suhu Operasi

-20°~+85°

Distorsi TV

<-80%

  Suhu Panyimpenan -20°~+85°
CH3596A-5
Lensa Fisheye Sudut Lebar 1/3" 1.3mm 220 Derajat Kanthi Pemasangan M12
Gambar PDF

Model

CH3596A

Tipe

Lensa Mata Iwak

Sederek lara.

>90%

Resolusi

5MP

Kepala Ray Angle

<20º

Format Gambar

1/3″

MOD

0.1m~∞

Lingkaran Gambar

f3.6mm (V-MAX)

Tipe Pemasangan

M12*P0.5

EFL

1.3mm

Gambar Dimensi

ф14.00-∅16.00*P 10.84mm

TTL (Teks Lengkap)

13mm

Struktur Lensa

6G Kabeh Kaca

F/ORA.

1.8

Filter IR

Non-IR

FFL(M)

2.16mm

Bobot

5.0g

BFL(O)

3,06mm

 Tahan banyu

IP68

Kanggo Sensor

PS5268

 Operasi Iris

Didandani

FOV (Foto)

Horisontal

230°

 Operasi Zoom

Didandani

Vertikal

148°

 Operasi Fokus

Pandhuan

Diagonal

230°

 Suhu Operasi

-20°~+85°

Distorsi TV

<-80%

  Suhu Panyimpenan -20°~+85°
CH3635C-1
Lensa Fisheye Sudut Lebar 1/3" 1.8mm 155 Derajat M12
Gambar PDF

Model

CH3635A

Resolusi

MP

Kepala Ray Angle

<22°

Format Gambar

1/3″

MOD

0.1m~∞

Lingkaran Gambar

f6.0mm (MAX)

Tipe Pemasangan

M12*P0.5

EFL

1.8mm

Gambar Dimensi

ф14.0*P11.30mm

TTL (Teks Lengkap)

14,80mm

Struktur Lensa

6G

F/ORA.

2.4

Filter IR

T=50% &650±10nm

FFL(M)

3.5mm

Tahan banyu

No

BFL(O)

3.7mm

Bobot

—

Kanggo Sensor

1/3″

Operasi Iris

Didandani

FOV (Foto)

Horisontal

155°

Operasi Zoom

Didandani

Vertikal

125°

Operasi Fokus

Pandhuan

Diagonal

190°

Suhu Operasi

-20° ~+85°

Distorsi TV

<-80%

Suhu Panyimpenan

-20° ~+85°

Sederek lara.

>90%
CH3635C-1
Lensa Sudut Lebar 1/3" 1.8mm 155 Derajat F2.4 IP67 M12
Gambar PDF

Model

CH3635B

Resolusi

MP

  Kepala Ray Angle <22°

Format Gambar

1/3″

MOD

0.1m~∞

Lingkaran Gambar

f6.0mm (MAX)

Tipe Pemasangan

M12*P0.5

EFL

1.8mm

Gambar Dimensi

ф14.0*P11.30mm

TTL (Teks Lengkap)

14,80mm

Struktur Lensa

6G

F/ORA.

2.4

Filter IR

Non-IR

FFL(M)

3.15mm

Tahan banyu

IP67

BFL(O)

3,70mm

Bobot

3.6g

Kanggo Sensor

1/3″

Operasi Iris

Didandani

FOV (Foto)

Horisontal

155°

Operasi Zoom

Didandani

Vertikal

125°

Operasi Fokus

Pandhuan

Diagonal

190°

Suhu Operasi

-20°~+85°

Distorsi TV

<-80%

Suhu Panyimpenan

-20°~+85°

Sederek lara.

>90%
CH3803B-2
Lensa Fisheye 1/2.9" 1.71mm 8MP F2.2 170 Derajat M7 Mount
Gambar PDF

Model

CH3803B

Resolusi

8MP

  Kepala Ray Angle <18°

Format Gambar

1/2.9″

MOD

0.1m~∞

Lingkaran Gambar

ф6.4mm (MAX)

Tipe Pemasangan

M7*P0.35

EFL

1.71mm

Gambar Dimensi

ф12.0*P10.62mm

TTL (Teks Lengkap)

13,26mm

Struktur Lensa

4G2P

F/ORA.

2.2

Filter IR

Non-IR

FFL(M)

2.64mm

Tahan banyu

—

BFL(O)

3,60mm

Bobot

—

Kanggo Sensor

1/2.9″

Operasi Iris

Didandani

FOV (Foto)

Horisontal

170°

Operasi Zoom

Didandani

Vertikal

100°

Operasi Fokus

Pandhuan

Diagonal

200°

Suhu Operasi

-20°~+85°
Distorsi F-Theta

<-6%

Suhu Panyimpenan

-20°~+85°

Sederek lara.

>68%

Kaya jenenge, Lensa Fisheye Seri 1/3" digawe kanggo kamera nganggo sensor 1/3'' utawa luwih cilik. Antarane lensa seri iki, CH2503 nyedhiyakake sudut pandang ultra amba nganti 225 derajat sing ngluwihi bidang pandang normal lan dilengkapi rong jinis dudukan - M8 lan M12. Dimensine sing ringkes - ф14.00 * L13.10mm ndadekake sampurna kanggo aplikasi ing omah cerdas, kaya sensor gerakan, sensor mlebu, bel lawang video, lan liya-liyane, ing ngendi papan kanggo lensa tansah winates.

CH2503 dirancang kanggo nyedhiyakake bunderan gambar maksimal ф3.1mm. Digabungake karo sensor 1/3 inci, kayata OA4689, lensa fisheye CH2503 ngasilake gambar bunder kaya iki →ehrLensa-lensa iki kasusun saka lensa optik kaca lan wadhah logam, mula bisa digunakake ing suhu sing dhuwur lan endhek banget. Lensa-lensa iki dirancang lan digunakake ing macem-macem aplikasi kalebu 360VR, tampilan surround kendaraan, aplikasi industri, lan liya-liyane. Kanthi utawa tanpa pilihan Filter IR kasedhiya kanggo kabeh lensa iki. Lan ana macem-macem filter sing bisa dipilih.

sdv
fgn

Grafik perbandingan

model CH2503 CH3596 CH3635
Lingkaran Gambar f3.1mm f3.6mm f6.0mm
EFL 0,98mm 1.3mm 1.8mm
TTL (Teks Lengkap) 14,85mm 13mm 14,80mm
FOV (Foto) 225°225°225° 220°130°230° 155°125°190°
Tipe Pemasangan M8/M12 M12*P0.5 M12*P0.5
Struktur Lensa 6G 6G+1M 6G
